HDPE circular fish cage 200mm
,floating pipe fish cage
,anti-wave circular fish cage
-
Working MethodFriction Type
-
Power SourceElectric
-
Harvesting MachineryFishing Winch
-
Fishing MethodPurse Seining Machinery
-
Fishing Gear WinchNet Hauler
-
Fishing Auxiliary MachineryAuxiliary Winch
-
Floating Pipe Diameter200mm/250mm/315mm/350mm/400mm
-
MaterialHDPE Pipe
-
ShapeCircular
-
Production Capacity6000sets/Year
-
Max Water Depth50m
-
Wind Resistance12 Grade
-
Wave Resistance7m
-
Current Resistance1.2m/s
-
Frame Lifespan15 Years
-
CertificationCE, ISO9001:2008
-
Minimum Order Quantity5
-
Price1000
HDPE Circular Fish Cage 200mm Floating Pipe Anti-Wave Design
HDPE Floating Offshore Fish Farm
Product Features
Nanfengwang cage features exceptional wind, current, and wave resistance. Constructed with marine-grade HDPE pipe for extended durability and large capacity to maximize fish survival rates.
- Versatile deployment: Suitable for water depths from -6m to 50m
- Superior durability: Withstands 12-grade typhoons, 7m waves, and 1.2m/s currents
- Spacious design: Provides ample living and growing space for aquaculture
- Long lifespan: Frame lasts over 15 years
- Easy maintenance: Simple net replacement system
- Premium materials: Marine-spec HDPE pipe with high strength, toughness, and anti-aging properties
Technical Specifications
HDPE Round Floating Cage Frame
| Circumference (M) | Diameter of Floating Pipe (MM) | Diameter of Handrail Pipe (MM) | Diameter of Stand Pipe (MM) |
|---|---|---|---|
| 30 | 200mm | 90mm | 110mm |
| 40 | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 50 | 250mm | 110mm | 125mm |
| 60 | 250mm/315mm | 110mm | 125mm |
| 70 | 315mm | 110mm/125mm | 125mm |
| 80 | 315mm | 110mm/125mm | -- |
| 90 | 350mm | 125mm | -- |
| 100 | 350mm/400mm | 125mm | -- |
| 120 | 350mm/400mm | 125mm | -- |
| 150 | 350mm/400mm | 125mm | -- |
| 200 | 400mm | 125mm | -- |
HDPE Square Floating Cage Frame
| L*W (M) | Diameter of Floating Pipe (MM) | Diameter of Handrail Pipe (MM) | Diameter of Stand Pipe (MM) |
|---|---|---|---|
| 3m * 3m | 200mm | 90mm | 110mm |
| 4m * 4m | 200mm | 90mm | 110mm |
| 5m * 5m | 200mm | 90mm | 110mm |
| 6m * 6m | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 7m * 7m | 250mm/315mm | 110mm | 125mm |
| 8m * 8m | 250mm/315mm | 110mm | 125mm |
| 9m * 9m | 250mm/315mm | 110mm | 125mm |
| 10m * 10m | 315mm | 110mm | 125mm |
| 12m * 12m | 315mm/350mm | 110mm/125mm | 125mm/-- |
| 15m * 15m | 315mm/350mm | 110mm/125mm | 125mm/-- |
| 20m * 20m | 350mm/400mm | 125mm | -- |
| 30m * 30m | 350mm/400mm | 125mm | -- |
Mooring System
Our deep-sea "Grid" mooring system connects cages with ropes and shackles, creating an interconnected group that moves uniformly. This design prevents collision damage even in severe sea conditions.
Why Choose Our Fish Farms?
- Annual production capacity of 50,000 tons
- High-quality materials and intelligent design ensure long service life
- Comprehensive after-sales service program
Ordering Process
- Provide your requirements including shape and diameter specifications
- For non-specialists: Send reference photos of your existing cage
- We'll recommend optimal sizing for your needs
- Receive our detailed quotation
- Finalize specifications upon agreement
- We professionally package and ship your fish farming cage
