HDPE Floating Cage with Round Shape and Deep Water Application for Marine Aquaculture
-
Highlight
HDPE Material Floating Cage
,Round Shape Fish Cage
,Deep Water Application HDPE Cage
-
Floating Pipe Diameter200mm/250mm/315mm/350mm/400mm
-
Handrail Pipe Diameter90mm/110mm/125mm
-
Stand Pipe Diameter110mm/125mm
-
Cage ShapeRound
-
Cage Diameter Range10m - 50m
-
Water Depth Range-6m To 50m
-
Wind Resistance12 Grade Typhoon
-
Wave Resistance7m Waves
-
Current Resistance1.2m/s
-
Frame Lifespan15 Years
-
Material TypeMarine HDPE
-
Material PropertiesHigh Strength, High Toughness, Anti-oxidant, Anti-aging
-
Circumference Range30m - 200m
-
Square Cage Dimensions3m*3m - 30m*30m
-
Production Capacity6000 Sets/year
-
Minimum Order Quantity5
-
Price1000
HDPE Floating Cage with Round Shape and Deep Water Application for Marine Aquaculture
HDPE/PE Floating Cage Features
Nanfengwang HDPE floating cages offer superior durability and performance for aquaculture operations. Engineered with marine-grade HDPE piping, these cages provide exceptional resistance to environmental conditions while maximizing fish survival rates.
- Versatile deployment in water depths ranging from 6m to 50m
- Exceptional weather resistance: withstands 12-grade typhoons, 7m waves, and 1.2m/s currents
- Optimized aquaculture capacity with spacious growing environment
- Extended service life exceeding 15 years for cage framework
- Convenient net replacement system
- Constructed with marine-spec HDPE piping featuring high strength, toughness, oxidation resistance, and UV protection
Structure Diagram
Technical Specifications
HDPE Round Floating Cage Frame
| Circumference (M) | Floating Pipe Diameter (MM) | Handrail Pipe Diameter (MM) | Stand Pipe Diameter (MM) |
|---|---|---|---|
| 30 | 200 | 90 | 110 |
| 40 | 200/250 | 90/110 | 110/125 |
| 50 | 250 | 110 | 125 |
| 60 | 250/315 | 110 | 125 |
| 70 | 315 | 110/125 | 125 |
| 80 | 315 | 110/125 | -- |
| 90 | 350 | 125 | -- |
| 100 | 350/400 | 125 | -- |
| 120 | 350/400 | 125 | -- |
| 150 | 350/400 | 125 | -- |
| 200 | 400 | 125 | -- |
HDPE Square Floating Cage Frame
| Dimensions L×W (M) | Floating Pipe Diameter (MM) | Handrail Pipe Diameter (MM) | Stand Pipe Diameter (MM) |
|---|---|---|---|
| 3×3 | 200 | 90 | 110 |
| 4×4 | 200 | 90 | 110 |
| 5×5 | 200 | 90 | 110 |
| 6×6 | 200/250 | 90/110 | 110/125 |
| 7×7 | 250/315 | 110 | 125 |
| 8×8 | 250/315 | 110 | 125 |
| 9×9 | 250/315 | 110 | 125 |
| 10×10 | 315 | 110 | 125 |
| 12×12 | 315/350 | 110/125 | 125/-- |
| 15×15 | 315/350 | 110/125 | 125/-- |
| 20×20 | 350/400 | 125 | -- |
| 30×30 | 350/400 | 125 | -- |
Advanced Mooring System
Our proprietary "Grid" mooring system ensures stability in deep sea or freshwater applications. This interconnected design links multiple cages through a network of ropes and shackles, creating a unified structure that moves collectively. This innovative approach prevents destructive collisions between cages, even in challenging sea conditions.
