HDPE Floating Fish Cage with 7m Wave Resistance 1.2m/s Current Resistance and 15-Year Lifespan for Deep Sea Aquaculture
-
Highlight
7m Wave Resistant HDPE Floating Fish Cage
,1.2m/s Current Resistant Circular Fish Cage
,15-Year Lifespan Deep Sea Aquaculture Cage
-
Floating Pipe Diameter200mm/250mm/315mm/350mm/400mm
-
Handrail Pipe Diameter90mm/110mm/125mm
-
Stand Pipe Diameter110mm/125mm
-
Circumference Range30m-200m
-
Square Cage Dimensions3m*3m To 30m*30m
-
Water Depth Range-6m To 50m
-
Wind Resistance12 Grade Typhoon
-
Wave Resistance7m Waves
-
Current Resistance1.2m/s
-
Frame Lifespan15+ Years
-
Material TypeMarine HDPE
-
Material PropertiesHigh Strength, High Toughness, Anti-oxidant, Anti-aging
-
Round Cage Diameters10m-50m
-
Production Capacity6000 Sets/year
-
Mooring SystemGrid System
-
Minimum Order Quantity1
HDPE Floating Fish Cage with 7m Wave Resistance 1.2m/s Current Resistance and 15-Year Lifespan for Deep Sea Aquaculture
High Quality Storm and Wave Resist Square Deep Sea Floating Aquaculture Fish Farming Cages
Product Features
Nanfengwang aquaculture cages offer exceptional resistance to wind, currents, and waves. Constructed from marine-grade HDPE piping, these durable cages provide large capacity for optimal fish growth and high survival rates.
- Versatile deployment in water depths ranging from 6m to 50m
- Superior wind resistance (up to 12-grade typhoons)
- Exceptional wave resistance (up to 7m waves)
- Strong current resistance (up to 1.2m/s)
- Spacious aquaculture capacity for optimal fish growth
- Extended service life - frame lasts over 15 years
- Easy net replacement system
- Marine-spec HDPE piping: high strength, toughness, and UV/oxidation resistance
Structure Diagram
Technical Specifications
HDPE Round Floating Cage Frame Specifications
| Circumference (M) | Floating Pipe Diameter (MM) | Handrail Pipe Diameter (MM) | Stand Pipe Diameter (MM) |
|---|---|---|---|
| 30 | 200mm | 90mm | 110mm |
| 40 | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 50 | 250mm | 110mm | 125mm |
| 60 | 250mm/315mm | 110mm | 125mm |
| 70 | 315mm | 110mm/125mm | 125mm |
| 80 | 315mm | 110mm/125mm | -- |
| 90 | 350mm | 125mm | -- |
| 100 | 350mm/400mm | 125mm | -- |
| 120 | 350mm/400mm | 125mm | -- |
| 150 | 350mm/400mm | 125mm | -- |
| 200 | 400mm | 125mm | -- |
HDPE Square Floating Cage Frame Specifications
| Dimensions L×W (M) | Floating Pipe Diameter (MM) | Handrail Pipe Diameter (MM) | Stand Pipe Diameter (MM) |
|---|---|---|---|
| 3m × 3m | 200mm | 90mm | 110mm |
| 4m × 4m | 200mm | 90mm | 110mm |
| 5m × 5m | 200mm | 90mm | 110mm |
| 6m × 6m | 200mm/250mm | 90mm/110mm | 110mm/125mm |
| 7m × 7m | 250mm/315mm | 110mm | 125mm |
| 8m × 8m | 250mm/315mm | 110mm | 125mm |
| 9m × 9m | 250mm/315mm | 110mm | 125mm |
| 10m × 10m | 315mm | 110mm | 125mm |
| 12m × 12m | 315mm/350mm | 110mm/125mm | 125mm/-- |
| 15m × 15m | 315mm/350mm | 110mm/125mm | 125mm/-- |
| 20m × 20m | 350mm/400mm | 125mm | -- |
| 30m × 30m | 350mm/400mm | 125mm | -- |
Mooring System
Our advanced "Grid" mooring system for deep sea and freshwater applications utilizes ropes and shackles to secure cages in a unified grid formation. This innovative design interconnects all cages as a single group - when one cage moves, all move in coordination. This mutual restraint system prevents destructive collisions between cages, even in severe sea conditions.
